Features
With a design that fits in your hand and a lightweight body, you can stably apply force even when you hold it in one hand and take measurements.
It can be used continuously for up to 30 hours, making it safe to carry and use in environments where charging is not possible.
Charging is also possible from a computer or mobile battery.
Connect to a PC via USB and easily manage data using the included software Force Logger.
The range below 50N is equipped with a mechanical stopper to reduce the risk of overload.
Since it has a calibration time notification function, a notification will be displayed when the preset calibration time approaches, helping you manage your measuring instruments reliably.

Use
Various compression/tension measurements.
Strength measurement of various materials.
Measurement of operating force for products and parts.
Package peel strength measurement.

Specification
Measurement range (N): 0 to 50
Resolution (N): 0.01
Maximum allowable load (N): 50
Width (mm): 72
Depth (mm): 32
Height (mm): 181
Measurement Accuracy: 0.2%F.S.1digit
Power supply (V): Battery type (USB power supply, AC adapter included)
Power supply: Battery type (USB power supply, AC adapter included)

Specification2
Sampling speed: up to 1000 times/sec

Material/Finish

Set contents/accessories
USB cable
AC adapter
Attachments (attached items vary depending on the range)
Carrying case
Instruction manual
Inspection report

caution
Please use with care to avoid damage due to overload (overload).
