Features
This is the successor model of the GEK/GEKR series digital ratchet.
Excellent workability as it notifies you through sound, light and vibration when the target torque has been reached.
Five pass/fail judgment settings can be set.
Equipped with a backlight and a larger display screen than the GEK/GEKR series for excellent visibility. – Excellent visibility due to three colors of yellow, green, and red light emission.
It uses a reusable 18650 type lithium-ion rechargeable battery as its power source, making it highly economical.
You can save 200 measurement data in the digital ratchet body and check the work results.

Use
Various manufacturing industries such as industrial machinery, analytical equipment, and automobiles.
Measurement of fastening torque.

Specification
Torque adjustment range (Nm): 20 to 100
Minimum scale (Nm): 0.1
Drive angle (mm): 9.5
Overall length (mm): 276
Power supply (V): 18650 type lithium ion charging Battery (3.7V)

Specification2
Accuracy guaranteed torque range (Nm): 20 to 100
Torque accuracy: 3%+1digit
Load direction: Right, left

Material/Finish

Set contents/accessories

caution
Please use within the torque measurement range.
It is not waterproof.
To maintain measurement accuracy, we recommend periodic torque calibration.
